Honda Outboard BF20 SHU 20hp Short Shaft

Honda Outboard BF20 SHU 20hp Short Shaft

Regular price £3,085.00 GBP
Regular price Sale price £3,085.00 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

Please Note:

Inflatable boat not included.

UK Mainland shipping is £79.99 added at checkout

An outboard that produces 20 horsepower that is actually portable – It’s true. With ideally placed foldaway handles, they're perfect for any boat that needs pocket-sized power. You’ll notice how quiet this engine is so you don’t need to raise your voice when you raise the power. The exclusive Honda rubber mount device soaks up the vibrations, making your journey feel smooth too. This light 350cc engine is easy to start, due to the decompression system and a Programmed ignition (PGM IG). This system accurately delivers the right amount of fuel/air mixture to the twin cylinders, so when you fire up these Hondas – even from cold – they're ready, right from the word go. With a sleek design and sculpted lines which run all the way down to the super-slim hydrodynamic gear case, this means less drag and better fuel economy. With its stunning silver finish you’ll see right away it’s a Honda.







Easy starter

This engine has a decompression system which makes for easy starting. This makes the engine much easier to turn over with that initial pull on this manual recoil.

Easy Astern

In forward motion the propeller will drive the boat normally through water, but when in reverse it's a different story – unless you have a Honda. On other outboards, the propeller will turn in exhaust bubbles and wont ‘latch’ onto the water. Our unique reverse exhaust relief system directs the exhaust bubbles away from the propeller, so that it can 'grip' the water – instead of air. This means when you put it into reverse you get an instant response with much finer control.

Easy manual tilt

The light engine is easy to tilt up in stages. Lifting up or down, enables you to manually trim the boat to give you maximum fuel efficiency and performance. It also prevents damage happening to the propeller blades when you find yourself near rocks or the water’s edge

Easy on your wrist

This engine has a Forward Mount Shift Lever which means you can gear change with your fingertips. It's so much easier to operate than on other outboards, whether you're left or right-handed. Together with a soft-grip throttle handle and a twist-lock, it’s effortless. You can just roll the power on and off all day long or lock it off – similar to cruise control.



  • Engine
    Engine Type OHC - 2 cylinders
    Valves 4 valves
    Displacement (cc) 350
    Bore X Stroke (mm) 59 x 64
    Full Throttle Range (RPM) 5,000 - 6,000
    Rated Power (kW (PS)) 14.7
    Cooling System Water Cooled (with Thermostat)
    Fuel Delivery 1 carburettor with accelerator pump
    Ignition System Electronic PGM-IG
    Starting System Electric / Recoil starter
    Exhaust System Through propeller boss
    Gear Ratio 2.08
    Propeller Rotation Standard
    Engine Trim and Tilt Manual Tilt - 5 stages / Power Tilt
  • Function
    Electric Starter Y
    Battery Charging Capacity (AMP.) 12A (Electric) / 6A (Recoil)
  • Dimensions
    Transom Height (mm) 433
    Dry Weight (kg) 46.5
    Overall Length (mm) 650 (Tiller) / 640 (Remote)
    Overall Width (mm) 350
    Overall Height (mm) 1110



Also, check this out...

4Front Corrosion Protection

This engine goes through a four layer coating process. We first anodise the aluminium casing with our patented ‘Double Seal’ process. Then an epoxy primer is applied before the shimmering silver paint. For further protection from UV rays, we apply a clear resin topcoat to finish. And to be absolutely sure, a sacrificial anode is fitted and all connectors are waterproof.

The Honda way

Our founder, Soichiro Honda, wanted to ensure our outboard engines were cleaner, quieter and friendlier to the environment – so he made them 4-stroke. This made Honda pioneers in marine engine technology. Therefore, as you accelerate away, you can have peace of mind in the fact that the clean water you are boating through will be staying that way.

Watertight warranty

Every Honda Marine customer has the support of a domestic or professional warranty, so you’re covered whatever the use. It will also maintain the same value throughout its warranty period - that means your last day of cover is as good as your first. We think that’s pretty unbeatable too.
