Mercury F3.5 MH - 3.5hp Outboard Engine Short Shaft

Mercury F3.5 MH - 3.5hp Outboard Engine Short Shaft

£739.95 GBP
£739.95 GBP
Sale Sold out
Tax included. Shipping calculated at checkout.

UK Mainland Shipping is £49.95 added at Checkout

 Mercury F3.5 MH - 3.5hp Outboard Engine Short Shaft

ENGINE DETAILS

Delivers lightweight, portable power and thrust for exact operation. Perfect for aluminum tiller, inflatable soft hull, jon, utility, and sail boats.

SPECIFICATIONS - 3.5

HP / kW
  • 3.5 / 2.6
Engine type
  • 1 cylinder
Displacement (CID/CC)
  • 5.2 / 85
Full throttle RPM
  • 5000-6000
Fuel induction system
  • 2-valve pushrod (overhead valve)
Recommended fuel
  • Unleaded 90RON minimum
Recommended oil
  • Mercury FourStroke Oil 10W-30
Engine protection operator warning system
  • Over-rev
Starting
  • Manual
Steering
  • Tiller with 360° turning
Shaft length
  • 15" / 381 mm
  • 20" / 508 mm
Gearcase ratio
  • 2.15:1
Dry weight *Lightest model available
  • 41 lbs / 18 kg
CARB star rating
  • 3
Bore and stroke
  • 2.16 x 1.42" / 55 x 36 mm
Ignition
  • CDI w/electronic spark advance
Fuel system
  • Carbureted
Cooling system
  • Water-cooled with thermostat
Gear shift
  • F-N
Gearcase options
  • Standard
Trim system
  • 4 position
Trim positions
  • 4
Exhaust system
  • Above prop
Shallow water trim range (degrees)
  • 16
Integrated fuel tank (gal / L)
  • 0.3 / 1.1
Color
  • Phantom Black
